Fiber Indexing by CommScope

CommScope’s pre-connectorized plug-and-play solution allows to:

  • deploy fiber up to 75% faster
  • reduce the amount of cable required by up to 70%
  • eliminate the need for fiber splicing

How? By changing from a star to a daisy-chain topology for connecting service terminals, and consolidating functionality into the service terminal. By using hardened service terminals with hardened multi-fiber connectors, this architecture combines the advantages of a daisy chain-topology with plug-and-play connectivity.





How Does Fiber Indexing Compare?




Traditional Network

Fiber Indexing Network

Benefits of Indexing

Fiber Distribution Hub

Serves ~240 homes

Serves ~240 homes

-

Fiber connections
at the fiber distribution hub

Spliced

Pre-connectorized cables to the terminals

10-15 minutes to plug in cables compared to over 4 hours for splicing individual fibers

Network topology
from fiber distribution hub to service terminal

Star (hub and spoke)

daisy-chain

Standardized lengths of cables simplifies logistics

Total cable length
from hub to service terminal

20,025 Feet

5,530 Feet

70% reduction in cable laying costs and conduit space required

Service Terminal Functionality

Fan-out (breaks out 8-fiber cable to individual ports)

Fan-out, splitter, and pass-through

Functions of network elements are redistributed to support indexing (no net benefit

Drop Cable
from terminal to the home

Single hardened drop cable

Single hardened drop cable
